Beskrivning
E/A-expansionsmodul för modulär SPS-styrreläer Zelio Logic SR3. Totalt 14 E/A, varav 8 digitala ingångar, 6 digitala utgångar. Spänningsförsörjning via SPS-styrreläer. De digitala utgångarna är konstruerade som transistorer. Kapslingsklass klämlist IP20, kapslingsklass frontplatta IP54. Montering på 35 mm din-skena. Certifierad enligt CE, cULus Listed, CSA, GL, GOST, C-Tick.
E/A-expansionsmodul för modulär SPS-styrreläer Zelio Logic SR3. Totalt 14 E/A, varav 8 digitala ingångar, 6 digitala utgångar. Spänningsförsörjning via SPS-styrreläer. De digitala utgångarna är konstruerade som transistorer. Kapslingsklass klämlist IP20, kapslingsklass frontplatta IP54. Montering på 35 mm din-skena. Certifierad enligt CE, cULus Listed, CSA, GL, GOST, C-Tick.
- Typ av produkt
- PLC-expansionsmodul
- Typ
- SR3XT141JD
- Tillverkarnr.
- SR3XT141JD
- Width
- 72
- Height
- 90
- Depth
- 59.5
- Switching current
- 8
- With time switch clock
- FALSE
- With display
- FALSE
- Suitable for safety functions
- FALSE
- Number of digital inputs
- 8
- Number of digital outputs
- 6
- Number of analogue inputs
- 0
- Number of analogue outputs
- 0
- Voltage type (supply voltage)
- AC/DC
- Supporting protocol for LON
- FALSE
- Number of HW-interfaces industrial Ethernet
- 0
- Number of HW-interfaces RS-232
- 0
- Number of HW-interfaces RS-422
- 0
- Number of HW-interfaces RS-485
- 0
- Number of HW-interfaces serial TTY
- 0
- Number of HW-interfaces USB
- 0
- Number of HW-interfaces parallel
- 0
- Number of HW-interfaces other
- 0
- With optical interface
- FALSE
- Supporting protocol for TCP/IP
- FALSE
- Supporting protocol for ASI
- FALSE
- Supporting protocol for PROFIBUS
- FALSE
- Supporting protocol for CAN
- FALSE
- Supporting protocol for INTERBUS
- FALSE
- Supporting protocol for KNX
- FALSE
- Supporting protocol for Modbus
- FALSE
- Supporting protocol for Data-Highway
- FALSE
- Supporting protocol for DeviceNet
- FALSE
- Supporting protocol for SUCONET
- FALSE
- Supporting protocol for other bus systems
- FALSE
- Redundancy
- FALSE
- With relay output
- TRUE
- Suitable for rail mounting
- TRUE
- Explosion safety category for gas
- None
- Explosion safety category for dust
- None
- Appendant operation agent (Ex ia)
- FALSE
- Appendant operation agent (Ex ib)
- FALSE
- Degree of protection (IP)
- IP20
- Supporting protocol for SERCOS
- FALSE
- Supporting protocol for INTERBUS-Safety
- FALSE
- Number of interfaces PROFINET
- 0
- Number of HW-interfaces wireless
- 0
- Front built-in possible
- TRUE
- Rack-assembly possible
- FALSE
- Wall mounting/direct mounting
- TRUE
- Expansion device
- TRUE
- Radio standard Bluetooth
- FALSE
- Radio standard WLAN 802.11
- FALSE
- Basic device
- TRUE
- IO link master
- FALSE
- Performance level according to EN ISO 13849-1
- None
- Supporting protocol for AS-Interface Safety at Work
- FALSE
- Supporting protocol for DeviceNet Safety
- FALSE
- Supporting protocol for EtherNet/IP
- FALSE
- Supporting protocol for Foundation Fieldbus
- FALSE
- Supporting protocol for PROFINET CBA
- FALSE
- Supporting protocol for PROFINET IO
- FALSE
- Supporting protocol for PROFIsafe
- FALSE
- Supporting protocol for SafetyBUS p
- FALSE
- Radio standard GPRS
- FALSE
- Radio standard GSM
- FALSE
- Mobile communications standard 3G (UMTS)
- FALSE
- SIL according to IEC 61508
- None
