Siemens 5SV13166LK10 Jordfelsbrytare/Säkerhetsbrytare

Siemens 5SV13166LK10 Jordfelsbrytare/Säkerhetsbrytare

Det ursprungliga priset var: kr1,790.00.Det nuvarande priset är: kr358.00.

Typ av produkt Jordfelsbrytare/Säkerhetsbrytare RoHS-godkänd Ja Innehåll 1 Voltage type AC Built-in depth 70 Rated current 10 Rated voltage 230 Release characteristic B Rated insulation voltage Ui 253 Rated fault current 0.03 Leakage current type A Surge current capacity 3 Current limiting class 3 Overvoltage category 2 Pollution degree 2 Width in number of modular spacings 1 Degree of protection (IP) IP20 Number of protected poles 1 Concurrently switching neutral conductor TRUE Rated short-circuit breaking capacity according to IEC 60947-2 25 With interlocking device TRUE Number of poles (total) 2 Anti-nuisance tripping version TRUE Rated impulse withstand voltage Uimp 4…

Kassa
SKU: FHGOFBV8330598314599
Category:

Beskrivning

Typ av produkt
Jordfelsbrytare/Säkerhetsbrytare
RoHS-godkänd
Ja
Innehåll
1
Voltage type
AC
Built-in depth
70
Rated current
10
Rated voltage
230
Release characteristic
B
Rated insulation voltage Ui
253
Rated fault current
0.03
Leakage current type
A
Surge current capacity
3
Current limiting class
3
Overvoltage category
2
Pollution degree
2
Width in number of modular spacings
1
Degree of protection (IP)
IP20
Number of protected poles
1
Concurrently switching neutral conductor
TRUE
Rated short-circuit breaking capacity according to IEC 60947-2
25
With interlocking device
TRUE
Number of poles (total)
2
Anti-nuisance tripping version
TRUE
Rated impulse withstand voltage Uimp
4
Rated short-circuit breaking capacity Icn according to EN 61009-1
6
Disconnection characteristic
Short-time delayed
Rated short-circuit breaking capacity according to EN 61009
6
