Beskrivning

AFDD-MCB-Combination 230V, 6kA, 1+N, B, 25A Compact (1MW) SENTRON 5SV6 .The extensive accessories, such as the auxiliary switch, allow the functions to be extended in a wide variety of ways.

AFDD-MCB-Combination 230V, 6kA, 1+N, B, 25A Compact (1MW) SENTRON 5SV6 .The extensive accessories, such as the auxiliary switch, allow the functions to be extended in a wide variety of ways.

RoHS-godkänd

Ja

Mått.

(B x H x D) 18 x 90 x 68.5 mm

Innehåll

1

Djup

68.5

Höjd

90

Bredd

18

Utlösningskarakteristik

B

Voltage type

AC

Built-in depth

70

Rated current

25

Rated voltage

230

Release characteristic

B

Number of poles

2

Current limiting class

3

Pollution degree

2

Width in number of modular spacings

1

Degree of protection (IP)

IP20

Rated short-circuit breaking capacity according to EN 60898

6

Rated short-circuit breaking capacity according to IEC 60947-2

6

Rated switch current auxiliary device

6000

Control voltage type auxiliary equipment

AC

Additional equipment attached at delivery

Fire protection switch

Typ av produkt

Ljusbågsskydd
